Texas-instruments Logic Gates CD4011BE

Texas-instruments Logic Gates CD4011BE

CD4011BE Description

Texas-instruments, Texas Instruments Quad NAND Logic Gate, 3 V 18 V, 14 Pin, PDIP

✅ In stock 15+ Available

AED 2.10
AED 2.10
Sale Sold out

Free shipping on orders over AED 500

Logic Function
Mounting Type
Number Of Elements

💡 Need technical consultation or bulk pricing?

Speak with Expert

Genuine Product

2 Year Warranty

Fast Delivery

Specifications








  • Brand: Texas Instruments

  • Logic Function: NAND

  • Mounting Type: Through Hole

  • Number Of Elements: 4

  • Number of Inputs per Gate: 2

  • Schmitt Trigger Input: No

  • Package Type: PDIP

  • Pin Count: 14

  • Logic Family: 4000

  • Maximum Operating Supply Voltage: 18 V

  • Maximum High Level Output Current: -4.2mA

  • Maximum Propagation Delay Time @ Maximum CL: 120 ns @ 10 V, 250 ns @ 5 V, 90 ns @ 15 V

  • Minimum Operating Supply Voltage: 3 V

  • Maximum Low Level Output Current: 4.2mA

  • Dimensions: 19.3 x 6.35 x 4.57mm

  • Height: 4.57mm

  • Propagation Delay Test Condition: 50pF

  • Minimum Operating Temperature: -55 °C

  • Maximum Operating Temperature: +125 °C

  • Width: 6.35mm

  • Length: 19.3mm
